Lecroy SDA11000 Serial Data Analyzers

4 Ch; 11/6 GHz Serial Data Analyzer; 11 GHz, 40 GS/s 40 Mpts on 2 Ch; 6 GHz, 20 GS/s 20 Mpts on 4 Ch

Vertical System

Analog Bandwidth @ 50 Ω (-3 dB)11 GHz

Rise Time (typical)40 ps

Input Channels2 or 1

Bandwidth LimitersFull BW only

Input Impedance50 O ?à2.0%

Input CouplingDC, GND

Maximum Input Voltage?à4 Vpeak

Vertical Resolution8 bits; up to 11 bits with enhanced resolution (ERES)

Sensitivity2 mV¨C1 V/div ( fully variable,< 10 mV/div through zoom)

DC Gain Accuracy?à1.5% of full scale

Voltage Gain Accuracy11 GHz

Offset Range?à750 mV @ 2 mV¨C 141 mV/div ?à4 V @ 195 mV¨C1 V/div

Offset Accuracy?à(1.5% of full scale +1.5% of offset value +2 mV)

Horizontal System

TimebasesInternal timebase common to 4 input channels

Time/Division Range, Real Time10 ps/div¨C100 |ìs/div (standard memory) 10 ps/div¨C500 |ìs/div (-XL memory)

Time/Division RangeN/A

Time Interval Accuracy= 0.06/SR + (1 ppm, aging < 1 ppm/year * Reading) (rms)

Jitter Noise Floor< 350 fs rms measured with 35 ps rise time (typical)

Trigger and Interpolator Jitter< 2.5 ps rms (typical)

Sample Rate and Delay Time Accuracy?à1 ppm, aging < 1 ppm/year @ 25??C

Channel-Channel Deskew Range?à9 x time/div. Setting, or 25 ns, whichever is larger

External Timebase Reference (Input)N/A

Math & Zoom Traces8 independent zoom and 8 math or zoom traces

Acquisition System

Single-Shot Sample Rate/Ch40 GS/s on 1 Ch

Random Interleaved Sampling (RIS)N/A

Maximum Trigger Rate150,000 waveforms / second

Intersegment Time6 |ìs

Maximum Acquisition Points/Ch2 Ch

Standard Memory (4 Ch / 2 Ch / 1Ch) (Number of Segments)40 M

XL ¨C Memory Option100 M

Acquisition Processing

AveragingSummed averaging to 1 million sweeps; continuous averaging to 1 million sweeps

Enhanced Resolution (ERES)From 8.5 to 11 bits vertical resolution

Envelope (Extrema)Envelope, floor, or roof for up to 1 million sweeps

Triggering System

ModesNormal, Auto, Single, and Stop

SourcesAny input channel, External, Ext X 10, Ext ??10, or line; slope and level unique to each source (except line trigger)

Coupling ModeDC

Pre-trigger DelayDelay 0¨C100% of memory size (adjustable in 1% increments)

Post-trigger Delaythe smaller of 0¨C10,000 divisions or 86400 seconds

Hold-off by TimeFrom 2 ns up to 20 s or from 1 to 99,999,999 events

Internal Trigger Range?à5 div from center

Trigger Sensitivity with Edge Trigger (Ch 1¨C4)3 div @ = 5 GHz, 2 div @ < 4 GHz, 1.2 div @ < 3 GHz (typical)

External Trigger Sensitivity300 mV @ = 5 GHz, 200 mV @ < 4 GHz, 120 mV < 3 GHz (typical)

External Trigger Input RangeAux (?à0.4 V); Aux X10 (?à0.04 V); Aux/10 (?à4 V)

Max. Trigger Frequency, SMART Trigger750 MHz @ = 10 mV

Basic Triggers

Edge/ Slope/ LineTriggers when signal meets slope and level condition.

SMART Triggers

State or Edge QualifiedTriggers on any input source only if a defined state or edge occurred on another input source. Delay between sources is selectable by time or events.

DropoutTriggers if signal drops out for longer than selected time between 2 ns and 20 s.

PatternLogic combination (AND, NAND, OR, NOR) of 5 inputs* ¨C 4 channels and external trigger input. Each source can be high, low, or don?ˉt care. The High and Low level can be selected independently. Triggers at start or end of the pattern.

SMART Triggers with Exclusion Technology

GlitchTriggers on positive or negative glitches with widths selectable from 600 ps to 20 s, or on intermittent faults

Signal or Pattern WidthTriggers on positive or negative pulse widths selectable from 600 ps to 20 s, or on intermittent faults

Signal or Pattern IntervalTriggers on intervals selectable between 2 ns and 20 s.

Setup and Waveform Storage

Front Panel and Instrument StatusStore to the internal hard drive or to a USB-connected peripheral device.

Power Requirements

Voltage100¨C120 VAC ?à10% at 50/60/400 Hz; 200¨C240 VAC ?à10% at 50/60 Hz; Automatic AC Voltage Selection

Max. Power Consumption800 VA (800 W)

Electrical Characteristics

Risetime (typical)28 ps

Environmental and Safety

Temperature (Operating)+5 ??C to +40 ??C including CD-ROM drives

Temperature (Non-Operating)¨C20 ??C to +60 ??C

Humidity (Operating)5% to 80% relative humidity (non-condensing) up to +30 ??C. Upper limit derates to 25% relative humidity (non-condensing) at +40 ??C.

Humidity (Non-Operating)5% to 95% relative humidity (non-condensing) as tested per MIL-PRF-28800F

Physical Dimensions

Dimensions (HWD)310 mm x 447 mm x 500 mm; 12.2" x 17.6" x 19.7" (height excludes feet)

Weight27 kg; 59 lbs.

Shipping Weight36 kg; 80 lbs.

Warranty and Service

Warranty and Service3-year warranty; calibration recommended annually. Optional service programs include extended warranty, upgrades, and calibration services.
